    G657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow Color

    Ask Lasest Price
    Brand Name : XDK
    Model Number : Fiber Optic Patch Cord FC/APC-FC/APC
    Certification : ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 5-8 work days
    Supply Ability : 5 million termination/month
    • Product Details
    • Company Profile

    G657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow Color

    Fiber Optic Patch Cord/ FC/APC-FC/APC/ Single mode G657A1/ Simplex/3.0mm/ LSZH/ PVC/Yellow


    Introduction

    Fiber optic patch cords suited for equipment jumper cable, cross connects and work area connections. All patch 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards. All of them have excellent environmental and mechanical performances.

    Our patch cord provides high reliability and flexibility for our customers in different industries. Our top-of-the-line fiber optic cable assemblies and stringent manufacturing process ensures the excellent optical performance. All patchcords can be customized in length, fiber mode and connector types to suit every single customer requirement with our state-of-art production facilities.

    G657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow ColorG657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow ColorG657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow Color


    Features

    1) Avalible in simplex, duplex connector options

    2) Fast delivery

    3) TIA compliant color-coded connectors and boots

    4) Cable jaket and boots color-coded for easy ID of fiber

    5) Fiber options: OS2, OM1,OM3, and OM4

    6) Fully tested for insertion loss and return loss

    7) Other jacket colors available as custom with MOQ and lead time applicable


    Specification

    Connector TypeFC/APC to FC/APCFiber CountSimplex
    Fiber ModeG657A1 9/125umWorking Wavelength1260~1625nm
    Insertion Loss≤0.3dBReturn Loss≥60dB

    Attenuation at 1310/1550nm

    (Typical)

    0.36/0.22 dB/kmFerrule MaterialsCeramic
    Cable Diameter3.0mmStrength MemberAramid yarn

    Minimum Bend Radius

    (Long term)

    10D

    Minimum Bend Radius

    (Short term)

    20D
    Cable JacketPVC / LSZHCable ColorYellow
    Operating Temperature-20~70°CStorage Temperature-40~85°C

    Our certificates
    1) ISO9002
    2) REACH
    3) ULE329066
    4) SGS, ROHS

    Quality G657A1 Simplex 3.0mm LSZH Fiber Optic Patch Cable Single Mode Yellow Color for sale
