    MTP / MPO To Dual MTP / MPO Female 24 Fiber OS2 Single Mode Conversion Harness


    MTP/MPO To Dual MTP/MPO Female 24 Fibers OS2 Single Mode Conversion Harness Cable Yellow


    Discription:


    MTP® conversion cable is designed to provide a more flexible multi-fiber cabling system based on MTP® products. Unlike MTP® harness cable, MTP® conversion cables are terminated with MTP® connectors on both ends, can provide more possibilities for the existing 24-fiber cabling system.

    The 40G/100G MTP® conversion cables eliminate the wasted fibers in current 40G transmissions and upcoming 100G transmission. Compared to purchase and install separate conversion cassettes, using MTP® conversion cables is a more cost-effective and lower-loss option.


    The specifications:


     END AEND B
    Connector TypeMTP/MPOMTP/MPOLCLC UnibootSC
    PolarityPolarity A, Polarity B, Polarity C
    IL(MTP/MPO)Standard ≤0.5 dB Ave ≤0.3dB
    IL(MTP/MPO)Elite: ≤0.35dB Ave: ≤0.2dB
    IL(LC/SC)Standard ≤0.25dB Low Loss : ≤0.15dB
    RLSM:≥60dB MM: ≥20dB
    Tester BrandEXFO & JGR
    Repeatability≤0.2dB
    Interchangeability≤0.2dB
    Mating1000 Times
    Opterating Temperature-20℃ ~ +70℃
    3D InterferometerFiber Height: 1000nm~3500nm
    Radius Long: 500mm min Radius Short: 50mm min Ferrule Height: 7.95mm min
    MM Core Dip: <100nm

    Features:


    - Ulitize MPO/MTP connectors

    - Inner: Ceramic Ferrule

    - Available in Elite insertion loss and standarad insertion loss.

    - Low loss elite versions are offered, featuring low insertion loww for demanding high speed networks where power budgets are critical.

    - They use a simple push-pull latching mechanism for easy and intuitive insertion and removal.

    - It provides up to 8, 12, 16, 24 times the density, thereby offering savings in circuit card and rack space.

    - Available in OS1/2, OM1, OM2, OM3 and OM4, OM5

    - Telcordia’s GR-326-Core, IEC Standard

    - Green Production, RoHS Standard

    - Interface polished type has PC, UPC and APC

    - Support use in attaching directly to 40/100G transceivers

    - 100% factory tested, with test results included for each assembly


    Company information:

    MTP / MPO To Dual MTP / MPO Female 24 Fiber OS2 Single Mode Conversion Harness


    Global footprints: 80 partners over 60 countries. Proving connectivity solution to more than 40 million people.


    FAQ:


    Q1. Can I have a sample order for this product?
    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


    Q2. What about the lead time?
    A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity.


    Q3. Do you have any MOQ limit for sample order?
    A: Low MOQ, 1pc for sample checking is available


    Q4. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.


    Q5. How to proceed an order for the product?
    A: Firstly let us know your requirements or application.
    B. Secondly We quote according to your requirements or our suggestions.
    C. Thirdly customer confirms the samples and places deposit for formal order.
    D. Fourthly We arrange the production.
