    SC - SC UPC Single Mode Armored Fiber Patch Cord With Low Insertion Loss

    Ask Lasest Price
    Brand Name : XDK
    Model Number : SC Patch Cord
    Certification : ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5 million termination/month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    SC - SC UPC Single Mode Armored Fiber Patch Cord With Low Insertion Loss

    Fiber Optic Cable Armored Patch Cord Sc-Sc Upc Single Mode Fiber Optic Patch Cord
    Feature
    1. The connectors are comply with IEC standards;
    2. Different size & color boot option;
    3. Low insertion loss; High return loss;
    4. 100% interferometer measurement;
    5. Various fiber cable option; G652D, G657A, G657B3, OM1, OM2, OM3, OM4 option;
    6. SC, FC, LC, ST, E-2000, MTRJ, MU, MTP, MPO, DIN, SMA-905/906, D4 available.
    SC - SC UPC Single Mode Armored Fiber Patch Cord With Low Insertion LossSC - SC UPC Single Mode Armored Fiber Patch Cord With Low Insertion Loss
    Parameters
    Item
    SM(Single Mode)
    MM(Multimode)
    Fiber Cable Type
    G652/G655/G657
    OM1
    OM2/OM3/OM4
    Fiber Diameter(um)
    9/125
    62.5/125
    50/125
    Cable OD(mm)
    0.9/1.6/1.8/2.0/2.4/3.0
    Connector Type
    SC
    Endface Type
    APC
    PC
    UPC
    UPC
    Typical Insertion Loss(dB)
    <0.2
    <0.2
    <0.1
    <0.1
    Return Loss(dB)
    >60
    >45
    -
    -
    Insert-pull Test(dB)
    <0.3
    <0.2
    <0.15
    -
    Interchangeability(dB)
    <0.15
    <0.1
    <0.1
    -
    Anti-tensile Force(N)
    -
    >70
    -
    -
    Temperature Range(℃)
    -40~+80
    Fiber Cable Characteristics
    MM
    G.651
    A1a.1:50/125
    Color:Orange or Other
    A1a.2:OM3
    Color:Aqua or Other
    A1a.3:OM4
    Color:Magenta or Other
    A1b:62.5/125
    Color:Orange or Other
    SM
    G.652D
    Color:Yellow or Other
    G.657(A1,A2,A3)
    Color:Green or Other
    Jacket Material
    PVC,LSZH or Other
